Parameters of 5000kg organic waste treatment equipment
| Product name |
Local organic waste treatment system |
Treatment method |
Biochemical degradation treatment |
| Product model |
CFCZ-YJ1000 |
Date of manufacture |
2017年Year |
| Basic technical parameters of products |
Rated voltage |
380V/ 50HZ |
Basic technical parameters of products |
Overall size |
10T biochemical machine 6456x 4518x 2480
conveying system
7000X 1500X 2300
Gas purification
1000X 650X 1080
|
| Daily processing capacity |
1000kg |
Packing method |
Wooden case transportation |
| Total power of crushing motor |
12KW |
Total power of mixing motor |
132KW
|
| Total power of winch motor |
11KW |
House size |
26m x15m X5m |
| Hoist power |
2.2KW |
Conveyor power |
0.4KW |
| Total heating power |
264KW |
Power unit motor |
1.1KW |
| Fan power |
350W |
Nameplate |
Han Bo |
| Treatment method |
Biochemical degradation reduction and volume reduction
|
Exhaust mode |
Circulating exhaust |
| Operating noise |
≤65dB |
Exhaust emission |
No waste discharge |
| Processing cycle |
2H |
Control mode |
PLC automatic control + loop button control |
| Body material |
All stainless steel body |
Crushing mode |
Tear and crush |
Functions of 5000kg organic waste treatment equipment
1.5000kg organic waste treatment equipment shall have the functions of sorting, crushing, extrusion, biochemical treatment, gas purification, etc.
2. The design service life of 5000kg organic waste treatment equipment is ≥ 10 years, the treatment equipment is sealed, there will be no leakage, and the ventilation capacity can be adjusted.
3.5000kg organic waste treatment equipment is equipped with PLC control, and the equipment operates automatically without manual intervention. PLC display screen can display working temperature, mixer, fan and other information. It is equipped with LCD touch screen, and all system data can be displayed.
4. Biochemical processor shall have the following functions:
(1) Degradation function: it can degrade organic waste components: after meal waste, organic waste, farmers' market waste, agricultural waste (such as towel gourd vine, potato vine, etc.), greening waste (leaves, rotten grass, etc.).
(2) Automatic feeding function: the processor product has an automatic feeding turnover device, one key operation, labor-saving and convenient.
(3) Deodorization function: the processor is equipped with a device, equipped with spraying, activated carbon purification, ultraviolet sterilization, filter and other functions. The odor concentration fully meets the indicators specified in gb14554.
(4) Automatic weighing function: the processor has automatic weighing function and is recorded in the system.
(5) Remote monitoring system: the processor uploads information (machine operation, amount of garbage handled, amount of fertilizer produced, etc.) to the information platform through the Internet.
(6) Automatic discharge function: the processor has automatic discharge function. Click the discharge button to discharge automatically.
5. The temperature range of the bin heating system can be adjusted and set through the PLC panel as required, and has overheating protection device;
6. The stop time of the mixing system in the machine bin can be adjusted and set through the PLC panel as required. The main mixing motor shall be equipped with overload protection device and manual control device
7.5000kg organic waste treatment equipment, and the decomposition rate of organic waste reaches more than 95
8. The noise, waste gas and waste water discharge of organic waste microbial processor shall comply with relevant national environmental protection standards.
9. Quality of organic fertilizer: the content of organic matter, total nutrient, water, pH, total arsenic, total mercury, total lead, total chromium and total cadmium of the organic fertilizer obtained after biochemical treatment meet the requirements specified in ny525-2012 standard
The sorting line of 10.5000kg organic waste treatment equipment has:
(1) Automatic feeding and feeding function, automatic cleaning function and automatic sewage collection function.
(2) Conveying capacity > 5000kg / h, crushing capacity: 5000 kg / h, conveying speed ≥ 5m / min.
(3) The sorting line can crush: including vines, crab shells, shellfish, bones, vegetables, peel and other organic waste, and the crushed particles are less than 5mm.
(4) The sorting line has the processing capacity matching with the microbial processor. After the organic waste is crushed, it meets the requirements of biochemical treatment.
(5) The crusher has automatic emergency stop function, automatic feeding function and combination with sorting line, and is equipped with linkage protection device;
(6) It is easy to open and clean and has double protection device; All electrical appliances meet the standards.
11.5000kg organic waste treatment equipment at ambient temperature ≥ 15 ℃, comprehensive energy consumption per unit treatment capacity ≤ 0.185kwh
The above is 5000kg organic waste treatment equipment and 5000kg organic waste treatment equipment manufacturer. As a manufacturer of organic waste treatment equipment, Hanbo technology will better introduce organic waste treatment equipment to you. Hanbo organic waste treatment equipment products have use cases in many places and units. Hanbo Environmental Technology Co., Ltd. welcomes you to consult and check.
